FilterMEP
POLYPROPYLENE STERILIZING GRADE MEMBRANE PLEATED FILTER CARTRIDGE
WITH POLYPROPYLENE SUPPORT LAYERS AND POLYPROPYLENE HARDWARE
FilterMEP is a filter cartridge designed for filtration of air and liquids.
FilterMEP filtermedia is thermally bonded and thermo bonded to the end-caps to assure integrity and
reduce extractables.
The FilterMEP filter cartridge is biologically inert.
All the cartridges are manufactured in a clean room, pre-flushed and tested 100% before shipment.
The polypropylene sterilizing grade membrane used in this cartridge is naturally hydrophic and can also be used for solvents.
The great performance of the FilterMEP cartridge is due to the specific and special polypropylene hydrophobic membrane sterilizing grade. This membrane provides a high particle retention and long life.
FilterMEP filtercartridge is available in filtration rating of 0,2 micron. The 0,2 micron rated cartridge meets the bacteria challange as per ASTM F838 05. FilterMEP is available in standard lengths of 10”, 20”, 30” and 40”. FilterMEP cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterMEP can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
The polypropylene sterilizing grade membrane used in this cartridge is naturally hydrophic and can also be used for solvents.
The great performance of the FilterMEP cartridge is due to the specific and special polypropylene hydrophobic membrane sterilizing grade. This membrane provides a high particle retention and long life.
FilterMEP filtercartridge is available in filtration rating of 0,2 micron. The 0,2 micron rated cartridge meets the bacteria challange as per ASTM F838 05. FilterMEP is available in standard lengths of 10”, 20”, 30” and 40”. FilterMEP cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterMEP can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
FilterNAF
NYLON 66 PHARMA GRADE MEMBRANE PLEATED FILTER CARTRIDGE
WITH NYLON 6 SUPPORT LAYERS AND NYLON HARDWARE
FilterMEP is a filter cartridge designed for filtration of air and liquids.
FilterMEP filtermedia is thermally bonded and thermo bonded to the end-caps to assure integrity and
reduce extractables.
The FilterMEP filter cartridge is biologically inert.
All the cartridges are manufactured in a clean room, pre-flushed and tested 100% before shipment.
The polypropylene sterilizing grade membrane used in this cartridge is naturally hydrophic and can also be used for solvents.
The great performance of the FilterMEP cartridge is due to the specific and special polypropylene hydrophobic membrane sterilizing grade. This membrane provides a high particle retention and long life.
FilterMEP filtercartridge is available in filtration rating of 0,2 micron. The 0,2 micron rated cartridge meets the bacteria challange as per ASTM F838 05. FilterMEP is available in standard lengths of 10”, 20”, 30” and 40”. FilterMEP cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterMEP can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
The polypropylene sterilizing grade membrane used in this cartridge is naturally hydrophic and can also be used for solvents.
The great performance of the FilterMEP cartridge is due to the specific and special polypropylene hydrophobic membrane sterilizing grade. This membrane provides a high particle retention and long life.
FilterMEP filtercartridge is available in filtration rating of 0,2 micron. The 0,2 micron rated cartridge meets the bacteria challange as per ASTM F838 05. FilterMEP is available in standard lengths of 10”, 20”, 30” and 40”. FilterMEP cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterMEP can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
FilterNAL
NYLON 66 MEMBRANE PLEATED FILTER CARTRIDGE
WITH NYLON SUPPORT LAYERS AND NYLON HARDWARE
FilterNAL cartridges have a single layer nylon 66 membranes developed for sterile filter applications
or sub-micron particle removal.
FilterNAL filtermedia is thermally bonded and thermo bonded to the end-caps to assure integrity and reduce extractables.
The membrane is supported by nylon layers that improve the strength and the service life time.
Stringent quality control standards guarantee a first class product with a consistent filtration performance.
All the cartridges are constructed and assembled in a clean room.
The FilterNAL filtercartridge is available in filtration rating of 0,2 / 0,45 / 0,65 / 0,8 and 1,2 micron. FilterNAL standard lengths are 10”, 20”, 30” and 40”. FilterNAL cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterNAL can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
FilterNAL filtermedia is thermally bonded and thermo bonded to the end-caps to assure integrity and reduce extractables.
The membrane is supported by nylon layers that improve the strength and the service life time.
Stringent quality control standards guarantee a first class product with a consistent filtration performance.
All the cartridges are constructed and assembled in a clean room.
The FilterNAL filtercartridge is available in filtration rating of 0,2 / 0,45 / 0,65 / 0,8 and 1,2 micron. FilterNAL standard lengths are 10”, 20”, 30” and 40”. FilterNAL cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterNAL can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
FilterNAP
NYLON 66 POSITIVE CHARGED MEMBRANE PLEATED FILTER CARTRIDGE
WITH NYLON 6 SUPPORT LAYERS AND NYLON HARDWARE
FilterNAP cartridges has nylon 66 positive charged pharmaceutical membranes developed for sterile filter applications or sub-micron particle removal.
FilterNAP filtermedia is thermally bonded and thermo bonded to the end-caps to assure integrity and reduce extractables.
The membranes are supported by nylon layers that improve the strength and the service life time.
Stringent quality control standards guarantee a first class product with a consistent filtration performance.
All the cartridges are constructed and assembled in a clean room.
The FilterNAP filtercartridge is available in filtration rating of 0,2 micron. FilterNAP standard lengths are 10”, 20”, 30” and 40”. FilterNAP cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterNAP can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
FilterNAP filtermedia is thermally bonded and thermo bonded to the end-caps to assure integrity and reduce extractables.
The membranes are supported by nylon layers that improve the strength and the service life time.
Stringent quality control standards guarantee a first class product with a consistent filtration performance.
All the cartridges are constructed and assembled in a clean room.
The FilterNAP filtercartridge is available in filtration rating of 0,2 micron. FilterNAP standard lengths are 10”, 20”, 30” and 40”. FilterNAP cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterNAP can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
FilterNYF
NYLON 66 PHARMA GRADE MEMBRANE PLEATED FILTER CARTRIDGE
WITH POLYPROPYLENE SUPPORT LAYERS AND POLYPROPYLENE HARDWARE
FilterNYF cartridges have nylon 66 pharmaceutical membranes developed for sterile filter applications
or sub-micron particle removal. FilterNYF filtermedia is thermally bonded and thermo bonded to the end-caps to assure integrity and reduce extractables.
The membranes are supported by polypropylene layers that improve the strength and the service life time.
Stringent quality control standards guarantee a first class product with a consistent filtration performance. All the cartridges are manufactured and assembled in a clean room and are 100% tested during the manufacturing and before shipment.
The FilterNYF filtercartridge is an excellent choice for the final filtration of liquids in the pharmaceutical, biological, food and beverage industry and/or in general suited for critical industrial applications.
The FilterNYF filtercartridge is available in filtration rating of 0,2 micron. FilterNYF standard lengths are 10”, 20”, 30” and 40” and in junior execution 2,5”and 5”. FilterNYFcartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterNYF can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
Stringent quality control standards guarantee a first class product with a consistent filtration performance. All the cartridges are manufactured and assembled in a clean room and are 100% tested during the manufacturing and before shipment.
The FilterNYF filtercartridge is an excellent choice for the final filtration of liquids in the pharmaceutical, biological, food and beverage industry and/or in general suited for critical industrial applications.
The FilterNYF filtercartridge is available in filtration rating of 0,2 micron. FilterNYF standard lengths are 10”, 20”, 30” and 40” and in junior execution 2,5”and 5”. FilterNYFcartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterNYF can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
FilterNYL
NYLON 66 MEMBRANE PLEATED FILTER CARTRIDGE
WITH POLYPROPYLENE SUPPORT LAYERS AND POLYPROPYLENE HARDWARE
FilterNYL cartridges have a single layer nylon 66 membranes developed for sterile filter applications
or sub-micron particle removal.
FilterNYL filtermedia is thermally bonded and thermo bonded to the end-caps to assure integrity and
reduce extractables.
The membranes are supported by polypropylene layers that improve the strength and the service life time. Stringent quality control standards guarantee a first class product with a consistent filtration performance.
All the cartridges are constructed and assembled in a clean room.
The FilterNYL filtercartridge is available in filtration rating of 0,2 / 0,45 / 0,65 and 0,8 micron. FilterNYL standard lengths are 10”, 20”, 30” and 40” and in junior execution 2,5”and 5”. FilterNYL cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterNYL can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
The membranes are supported by polypropylene layers that improve the strength and the service life time. Stringent quality control standards guarantee a first class product with a consistent filtration performance.
All the cartridges are constructed and assembled in a clean room.
The FilterNYL filtercartridge is available in filtration rating of 0,2 / 0,45 / 0,65 and 0,8 micron. FilterNYL standard lengths are 10”, 20”, 30” and 40” and in junior execution 2,5”and 5”. FilterNYL cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterNYL can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
FilterNYP
NYLON 66 POSITIVE CHARGED PHARMACEUTICAL MEMBRANE PLEATED FILTER CARTRIDGE
WITH POLYPROPYLENE SUPPORT LAYERS AND POLYPROPYLENE HARDWARE
FilterNYP cartridges have nylon 66 positive charged pharmaceutical membranes developed for sterile filter applications or sub-micron particle removal. FilterNYP filtermedia is thermally bonded and thermo bonded
to the end-caps to assure integrity and reduce extractables.
The membranes are supported by polypropylene layers that improve the strength and the service life time. Stringent quality control standards guarantee a first class product with a consistent filtration performance.
All the cartridges are manufactured and assembled in a clean room and are 100% tested during the manufacturing and before shipment.
The FilterNYP provides outstanding particulate and microbiological retention and especially aswell as at fine colloidal retention due to the positive charge.
The FilterNYP filtercartridge is available in filtration rating of 0,2 micron. FilterNYP standard lengths are 10”, 20”, 30” and 40” and in junior execution 2,5”and 5”. FilterNYP cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterNYP can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
The membranes are supported by polypropylene layers that improve the strength and the service life time. Stringent quality control standards guarantee a first class product with a consistent filtration performance.
All the cartridges are manufactured and assembled in a clean room and are 100% tested during the manufacturing and before shipment.
The FilterNYP provides outstanding particulate and microbiological retention and especially aswell as at fine colloidal retention due to the positive charge.
The FilterNYP filtercartridge is available in filtration rating of 0,2 micron. FilterNYP standard lengths are 10”, 20”, 30” and 40” and in junior execution 2,5”and 5”. FilterNYP cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterNYP can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
FilterNYV
NYLON 66 FOOD AND BEVERAGE GRADE MEMBRANE PLEATED FILTER CARTRIDGE
WITH POLYPROPYLENE SUPPORT LAYERS AND POLYPROPYLENE HARDWARE
IPM filtration systems deals in wine filtration for many years and has engineered and designed the ideal membrane structure, so that the wine will keep it’s unique properties like taste and color.
FilterNYV cartridges are membrane cartridge filters optimized for the use in beverage applications and in particular for wine. Due to the special protection layer, the life of the membranes and the service life interval will be longer than with the standard membrane filters. FilterNYV filtermedia is thermally bonded and thermo bonded to the end-caps to assure integrity and reduce extractables.
Stringent quality control standards guarantee a consistent filtration performance and controlled pore size. All the cartridges are manufactured and assembled in a clean room and are 100% tested during the manufacturing and before shipment and the materials used meet the requirements of the USP Class VI. FilterNYV cartridges are 100% traceable.
FilterNYV filtercartridge is available in filtration rating of 0,45 / 0,65 / 0,8 and 1,2 micron. FilterNYV standard lengths are 10”, 20”, 30” and 40”. FilterNYV cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterNYV can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
FilterNYV cartridges are membrane cartridge filters optimized for the use in beverage applications and in particular for wine. Due to the special protection layer, the life of the membranes and the service life interval will be longer than with the standard membrane filters. FilterNYV filtermedia is thermally bonded and thermo bonded to the end-caps to assure integrity and reduce extractables.
Stringent quality control standards guarantee a consistent filtration performance and controlled pore size. All the cartridges are manufactured and assembled in a clean room and are 100% tested during the manufacturing and before shipment and the materials used meet the requirements of the USP Class VI. FilterNYV cartridges are 100% traceable.
FilterNYV filtercartridge is available in filtration rating of 0,45 / 0,65 / 0,8 and 1,2 micron. FilterNYV standard lengths are 10”, 20”, 30” and 40”. FilterNYV cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterNYV can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
FilterPES
POLYETHERSULPHONE MEMBRANE PLEATED FILTER CARTRIDGE
WITH POLYPROPYLENE SUPPORT LAYERS AND POLYPROPYLENE HARDWARE
FilterPES cartridges are manufactured using the unique polyethersulphone membrane with
polypropylene support layers.
FilterPES filtermedia is thermally bonded and thermo bonded to the end-caps to assure integrity and
reduce extractables.
The polyethersulphone and the polypropylene layers have low protein binding in order to have a secured filter process. The cartridges doesn’t have any surfactants or binding materials in order to meet requirement for non-fiber release.
All the cartridges are manufactured and assembled in a clean room and are 100% tested during the manufacturing and before shipment and they are ‘in-situ’ testable, according to the integrity testing. FilterPES cartridges are 100% traceable.
FilterPES filtercartridge is available in filtration rating of 0,1 / 0,2 / 0,45 and 0,65 micron. FilterPES standard lengths are 10”, 20”, 30” and 40”. FilterPES cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterPES can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
The polyethersulphone and the polypropylene layers have low protein binding in order to have a secured filter process. The cartridges doesn’t have any surfactants or binding materials in order to meet requirement for non-fiber release.
All the cartridges are manufactured and assembled in a clean room and are 100% tested during the manufacturing and before shipment and they are ‘in-situ’ testable, according to the integrity testing. FilterPES cartridges are 100% traceable.
FilterPES filtercartridge is available in filtration rating of 0,1 / 0,2 / 0,45 and 0,65 micron. FilterPES standard lengths are 10”, 20”, 30” and 40”. FilterPES cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterPES can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
FilterTEF
TEFLON (PTFE) MEMBRANE PLEATED FILTER CARTRIDGE
WITH POLYPROPYLENE SUPPORT LAYERS AND POLYPROPYLENE HARDWARE
FilterTEF filter cartridge have been developed and optimized for filtration of high purity air and liquids to
assure end product quality and biological purity. FilterTEF filtermedia is thermally bonded and thermo
bonded to the end-caps to assure integrity and reduce extractables.
FilterTEF is inherently hydrophobic and contains no added surfactants or wetting agents. All the cartridges are manufactured and assembled in a clean room, pre-flushed and 100% integrity tested during production.
The PTFE membrane provides a high flow rate, long service life, and dependable and consistant removal of micro-organism and inorganic particulates. The FiltertTEF membrane is biological inert, having low protein binding characteristics. Bacterial retention is effective and meets the international standards.
FilterTEF filtercartridge is available in filtration rating of 0,1 / 0,2 / 0,45 micron. FilterTEF standard length’s are 10”, 20”, 30” and 40”. FilterTEF cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterTEF can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
FilterTEF is inherently hydrophobic and contains no added surfactants or wetting agents. All the cartridges are manufactured and assembled in a clean room, pre-flushed and 100% integrity tested during production.
The PTFE membrane provides a high flow rate, long service life, and dependable and consistant removal of micro-organism and inorganic particulates. The FiltertTEF membrane is biological inert, having low protein binding characteristics. Bacterial retention is effective and meets the international standards.
FilterTEF filtercartridge is available in filtration rating of 0,1 / 0,2 / 0,45 micron. FilterTEF standard length’s are 10”, 20”, 30” and 40”. FilterTEF cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterTEF can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
Filtervin
POLYETHERSULPHONE WINE AND BEVERAGE GRADE MEMBRANE PLEATED FILTER CARTRIDGE
WITH POLYPROPYLENE SUPPORT LAYERS AND POLYPROPYLENE HARDWARE
FilterVIN cartridges are manufactured using the unique polyethersulphone membrane with
polypropylene support layers. FilterVIN filtermedia is thermally bonded and thermo bonded to the end-caps to assure integrity and reduce extractables.
The polyethersulphone and the polypropylene layers have low protein binding in order to have a secured filter process. The cartridges doesn’t have any surfactants or binding materials in order to meet requirement for non-fiber release.
All the cartridges are manufactured and assembled in a clean room and are 100% tested during the manufacturing and before shipment and they are ‘in-situ’ testable, according to the integrity testing. FilterVIN cartridges are 100% traceable.
FilterVIN filtercartridge is available in filtration rating of 0,2 / 0,45 / 0,65 and 1,2 micron. FilterVIN standard lengths are 10”, 20”, 30” and 40”. FilterVIN cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterVIN can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
The polyethersulphone and the polypropylene layers have low protein binding in order to have a secured filter process. The cartridges doesn’t have any surfactants or binding materials in order to meet requirement for non-fiber release.
All the cartridges are manufactured and assembled in a clean room and are 100% tested during the manufacturing and before shipment and they are ‘in-situ’ testable, according to the integrity testing. FilterVIN cartridges are 100% traceable.
FilterVIN filtercartridge is available in filtration rating of 0,2 / 0,45 / 0,65 and 1,2 micron. FilterVIN standard lengths are 10”, 20”, 30” and 40”. FilterVIN cartridges are available with all standard end-cap adaptors (fin end, flat seal, 222, bajonet 226).
FilterVIN can be sterilized by steam or in autoclave with stainless steel insert (procedure as per USP).
